The USB Interface Converter in RS-485/422 (1-port USB to RS-485 RS-422 serial converters) allows one to connect the RS-485 or RS-422 bus to a PC via USB and a virtual COM port. The RS-485/422 interface has a 1000V galvanic isolation and is powered from USB. Made in a housing of USB stick.
The USB Interface Converter in RS-485/422 (1-port USB to RS-485 RS-422 serial converters) allows one to connect the RS-485 or RS-422 bus to a PC via USB and a virtual COM port. The RS-485/422 interface has a 1000V galvanic isolation and is powered from USB. Made in a housing of USB stick.
Functional capabilities:
• Converts the RS-485/422 consistent channel of communication in a virtual COM port, connecting to a PC via USB;
• Works up to 200 kbps. Works with any protocols, including ModBus or A-Bus;
• It has galvanic isolation up to 1000V;
• The module powered from USB. Connection to the RS-485 bus via two-wire cable, only A and B, to the RS-422 bus via four-wire cable, A B, Z, Y.
• Using internal jumpers, one can set two operating modes: 1) USB - RS-485; 2) USB - RS-422.
• Using internal jumpers, one can set two operating modes: 1) half duplex for RS-485; 2) full duplex for RS-422 or echo for RS-485.
-
Working temperatureот 0° С до 75° СRelative humidity20 - 90 %Type of shellUSB stick
-
